Bluegame
BGX70

HULL DECK CONSTRUCTION
Molded fiberglass construction made with iso- neopentilic gelcoat, skin coat of vinylester resin
Bottom hull in monolithic lamination made with biaxial, glass and ISO DCPD polyester resin
Sandwich core construction on side hull and deck plans Infused sandwich structural bulkheads

UPPER DECK
Antifouling and propspeed on Hull
Deck made in sandwich and infusion technology with vinylester resin
Twin fiberglass doors covering anchor system Anchor 50 Kg S/S
Bow roller custom design S/S
Galvanized chain 12 mm 100 m
Anchor safety cable
Electric anchor winch 2000 w
Electric mooring winch 1600 w
Two S/S fairlead
Two S/S cleats 360 mm
Two retractable cleats amidship
Fresh water outlet connection
Teak deck
Access to crew cabin at the bow
Sun pad area with back rest
Double side entrance from the dock
Two teak tables with electric up/down system in bow area
Bow sofa on both side
Storage
Navigation and anchor lights led systems Courtesy light on walkaround
Dimmable ceiling lights
Double diesel inlet
Fresh water inlet
Black water tank drain pump
Grey water tank drain pump
Horn
Radar radome
GPS antennas
VHF antennas
Four speakers (two in cockpit two in bow) connected to the deck house area
Upper deck sliding glass door
Port side manual pantograph door
L shape sofa on stern with teak table Glass skylight on portside
Storage
Sun roof ladder with manual hatch Sun roof handrails
Sun Pad with Teak allround
TV SAT Antenna

BEACH AREA
Two speakers and subwoofer connected to the salon area
Teak stairs to upper deck
Wetbar with fridge, sink and storage
Sliding door to main salon
Side 180° crane with 500 kg lifting capacity
Retractable up/down gangway
One electrical engine room big hatch for maintenance One manual engine room access
Two stern mooring winches 1600 W
Four stainless steel cleats 300 mm
Hot/cold shower
Teak deck
Side storage compartments
Floor storage comparments
Courtesy lights
Dimmable ceiling lights
Two glass skylights

DECKHOUSE
Sliding glass door with curtain Wooden floor
Blinds
Dimmable led lights
L shape sofa with table and 3 chairs/stools Pilot and copilot bench

Console with:
HI-FI
Compass
Three 12” chart plotter glass cockpit
Indicating engines parameters (rpm, oil pressure, water temperature, engine sound warning alarm, fuel and water level) and controls (intruder systems, windshield wiper, GPS, radar, fish-finder)
Volvo Penta automatic pilot
VHF station with passive AIS receiver
IPS Joystick
Bow thruster control
Volvo Penta electronic engine throttle
Digital switching and digital automation for main services DC and AC integrated in main panel
Back-lighted switch panel for deck services Bluegame personalised steering wheel
Fire control for manual extinguisher
Red navigation light control
Port side manual pantograph door Power and USB sockets
Stairs from main saloon with handrail Stairs to guest’s area with handrail Side tempered glass
Air conditioning fan coils Fire extinguisher 1 kg

GALLEY
Painted overhead cabinet
Lower painted cabinet with storage
Sink
Synthetic worktop
Four zone induction cooktop with pan holders Oven
Refrigerator
Freezer
Dishwasher
Kitchen hood
Power sockets
Trash compactor
SALON
Sliding door to beach area with curtain Steps from beach area to salon
Power and USB sockets
Dimmable lights
L shape fabric sofa
Two armachair Two coffee table Storage cabinet Wooden floor Carpet
Blinds
Side tempered glass
50” TV
Stairs to deckhouse
Owner cabin entrance HI-FI
Four speakers
Air conditioning fan coils Floor hatch to storage area Sockets 220 V
Fire extinguishers 1 Kg

OWNER CABIN
Double bed with mattresses memory foam Storage cabinet
Nightstands
Carpet floor
Reading lights
Ceiling lights
Courtesy lights
Power and USB sockets
Side tempered glasses with integrated porthole Blinds
Pillows
Bed sheet covers
Bed sheets
Bathroom towels
Safe
32” TV
HI-FI
Two speakers
Vanity desk with one stool Walk-in-wardrobe
Air conditioning fan coil Fire extinguisher 1 Kg

OWNER BATHROOM
Fresh water electric marine WC Bidet
Wooden floor
Ceiling Lights
Blind
Power and USB sockets
Bathroom accessories
Cabinet with mirror
Porthole
Synthetic surface with integrated double sink
Air conditioning outlet
Shower with handset, ceiling shower head and tempered glass door

VIP CABIN
Double bed with mattresses memory foam Storage cabinet
Nightstands
Wardrobe
Carpet floor
Reading lights
Ceiling lights
Courtesy lights
Power and USB sockets Two portholes
Blinds
Pillows
Bed sheets
Bathroom towels
Bed sheet covers
32” TV
HI-FI
Two speakers
Air conditioning fan coil Fire extinguisher 1 Kg

VIP BATHROOM
Fresh water electric marine WC Wooden floor
Ceiling lights
Blind
220 V sockets
Bathroom accessories
Cabinet with mirror
Porthole
Synthetic surface with integrated sink Air conditioning outlet
Shower with handset, ceiling shower head and tempered glass door
PLAY ROOM
U Sofa/convertible bed Wardrobe
Carpet floor
Reading lights
Ceiling lights
Courtesy lights
Power and USB sockets Porthole
Blinds
Pillows
Bed sheets
Bathroom towels
HI-FI
Two speakers
Air conditioning fan coil Fire extinguisher 1 kg

GUEST BATHROOM
Fresh water electric marine WC Wooden floor
Ceiling lights
Blind
220 V sockets
Bathroom accessories
Cabinet with mirror
Porthole
Synthetic surface with integrated double sink
Air conditioning outlet
Shower with handset, ceiling shower head and tempered glass door

LOBBY
Storage area with wash/dryer machine Teak stairs from deckhouse to lower deck Courtesy lights
Floor hatch to storage area

CREW CABIN
Two bunk beds Storage cabinet Reading lights Ceiling lights Porthole Synthetic floors
Storages below the pilot seat
Blinds
Pillows
Bed sheets
Power and USB sockets Air conditioning fan coil Separate bathroom with:
Fresh water electric Marine WC Synthetic floor
Ceiling lights
Power socket
Bathroom accessories Storage cabinet Porthole
Shower
Crew set uniform

ENGINE ROOM
2 x Volvo IPS 1200 D13 / 2 x 588 kW / 900 HP
4000 l fuel structural tank in composite with fuel level sender connected with EVC Volvo system 7
S/S daily tank in engine room 200 l
Automatic valves for fuel shout-off
Double fuel filter separator
Fire extinguisher system with manual and automatic control
Engine room led lights
AC chiller unit 96000 btu
Engine room insulation
Two electrical ventilators with cycle reversion and thermostat switch
Air inlet with water separator filters
Watertight power sockets
Water Filter
Opening engine room cover
Optical smoke detector
Overpressure detector integrated with Garmin automation
S/S engine room access ladder Intruder trim system

HYDRAULIC SYSTEM
1000 l polyethylene fresh water tank with level indication on main panel
Two boilers 50 l 220 V
Black water tank 330 l with level indication on main panel
Gray water tank 330 l with level indication on main panel Shore black water discharge system 24 V
Shore grey water and bilge discharge system 24 V
Double fresh water pump 24 / 230 V
Black water hoses in special anti smell rubber High pressure fresh water inlet from shore
Six bilge pumps; two in engine room, two in stern area and two in center hull, with automatic
and manual control
Salt water system for anchor chain wash

ELECTRICAL SYSTEMS
Generator 22,5 kW
Four batteries 12 V / 130 Ah AGM for engines
Electromechanical switching for batteries with remote control
8 Service Gel batteries pack 24 V / 660 Ah
One battery 12 V / 165 Ah for generator
Two Bow Thruster and winch batteries pack 12 V / 165 Ah Battery charger 24 V / 80 Ah for services
Battery charger 24 V / 30 Ah for engines
Battery charger for generator
230 V shore power 62 A with connection cable 15 m Galvanic Isolator 62 Ah
Inverter 2000 W
Electric bow thrusters 170 Kgf
AC Electrical Panel (230 V) CE certified on electrical room with electromechanical switching for all outlet with remote control on main panel
DC Electrical Panel (24 V) CE certified on electrical room with electromechanical switching for all outlet with remote control on main panel
